DOOSAN DL420A-7M

From the beginning, we had great concern for machine operators. People need to work in a well-designed and comfortable environment. The work area is spacious, with several places for storage. The checking and monitoring devices are comprehensive. There is an open view of the work area. For night work, operators are provided with powerful front and rear lighting.

Download Brochure
Previous Next
DOOSAN DL420A-7M
DOOSAN DL420A-7M

From the beginning, we had great concern for machine operators. People need to work in a well-designed and comfortable environment. The work area is spacious, with several places for storage. The checking and monitoring devices are comprehensive. There is an open view of the work area. For night work, operators are provided with powerful front and rear lighting.

CLASSIFICATION UNIT DL420A-7M
Operating weight Ton 21.95
Bucket Capacity (SAE) m3 3.5~4.5
Engine Rated Power (SAE j1349, net) kW/rpm 210/2,100
Engine Model - DE12TIS
Front Speed (Raise/Dump/Lower) sec 6.0 / 1.3 / 4.2
Height at Bucket Pivot Point mm 4,295
Breakout Force kN 197
Turning Radius at Tire Center mm 6,037
Tires (L3) 26.5-25-20PR
Overall Length mm 8,890
Overall Width mm 3,200
Overall Height mm 3,535
Static Tipping Load(straight) kg 17,820 (4.0m³)
